High Efficiency Planetary Gearbox Hybrid Stepper Motor NEMA 17 42mm

Place of Origin China
Brand Name VIC-TECH
Certification RoHS
Model Number 42BYG-42PLF
Minimum Order Quantity 1 Unit
Price $20.2-$38/unit
Packaging Details Selling Units: Single item plastic box inner , outer paper box Package: single carton packing, 100 - 1000 pieces per box. Lead Time : 30 Days After Deposit
Delivery Time 15-30 work days
Payment Terms MoneyGram, T/T, Western Union, T/T
Supply Ability 100000units/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Step Angle 0.9°/1.8 ° Current 0.4~1.7A/phase
Type Hybrid Stepper Motor Gear Ratio Multiple To Choose
Output Torque Motor's Torque*gear Ratio* Efficiency
High Light

High Efficiency Hybrid Stepper Motor

,

NEMA 17 Hybrid Stepper Motor

,

Planetary Gearbox Stepper Motor

Leave a Message
Product Description

NEMA 17 42mm high efficiency planetary gearbox hybrid stepper motor

This is a 42mm hybrid stepper motor (NEMA 17) attached with planetary gearbox.

There are several gearbox ratio for you to choose, from 4:1 to 79:1.

Base on different gear levels, gearbox will have different length and efficiency.

1 level: 35mm length, 95% efficiency

2 levels: 46mm length, 90% efficiency

Mechanical Dimension:MM

High Efficiency Planetary Gearbox Hybrid Stepper Motor NEMA 17 42mm 0

Typical Applications

  • Medical instruments

  • Precision instrument

  • Robot

  • Factory automation

  • Game machine

  • ATM equipment

  • Security equipment

Specifications



Motor type Hybrid stepper motor+planetary gearbox
Model 42BYG-42PLF
Excitation mode 2-2 bipolar
Output shaft Φ10h7
Gearbox type Planetary gearbox
0.4~1.7A/phase

4:1; 5:1; 7:1; 10:1; (1 level)

16:1; 20:1; 25:1; 28:1; (2 levels)

35:1; 40:1; 50:1; 79:1;

Output torque Motor’s torque*gear ratio*gearbox efficiency
Current range 0.4~1.7A/phase
Step angle 0.9°/18°




Competitive Advantage

  • High quality and the best price.
  • Fast deliver,storage company and rich inventory
  • Near Shanghai port, the traffic is very convenient.

Torque Curve For Reference



Type of Fixture Cover



The regular models are shown in the figure, and the special sizes can be customized.

High Efficiency Planetary Gearbox Hybrid Stepper Motor NEMA 17 42mm 1

Type of Wire Connect

Motor input method with Pin type, FPC, PCB, Lead wire etc.

These can be customized according to customer needs.

High Efficiency Planetary Gearbox Hybrid Stepper Motor NEMA 17 42mm 2

Product Detail Presentation

High Efficiency Planetary Gearbox Hybrid Stepper Motor NEMA 17 42mm 3



High Efficiency Planetary Gearbox Hybrid Stepper Motor NEMA 17 42mm 4
