High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit

  • High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit
  • High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit
  • High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit
  • High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit
  • High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit
Place of Origin Jiangsu, China (Mainland)
Brand Name VIC-TECH
Certification RoHS
Model Number VSM0613
Minimum Order Quantity 1Unit
Price $2~$5/Unit
Packaging Details Selling Units: Single item plastic box inner , outer paper box Package: single carton packing, 100 - 1000 pieces per box. Lead Time : 30 Days After Deposit
Delivery Time 15-30 work days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 1000000 Units/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Step Angle(degrees) 18 Degree Phase 2
Voltage 3.3V Current / Phase 280mA/Phase
Resistance 12Ω±10% Weight 1.58g
Rotation CW/CCW Type Permanent Magnet
Speed 3000rpm
Leave a Message
Product Description

6mm Long life micro stepper motor 2 phase 4 wire pm stepper motor for camera lenses

This product is a precision micro stepping motor body outer diameter 6MM, body length 7MM, shaft outer diameter 1MM, the shaft length can be appropriately changed according to the needs, and can be equipped with gears, pulleys, worms, screw rods, etc. Output device.
The motor has a basic step angle of 18 degrees and the motor runs 20 steps per week.
Because of its small size, high precision and easy control, this micro stepping motor is widely used in cameras, optical instruments, lenses, flashlights, precision medical equipment, automatic door locks and other fields.



High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit 0



Mechanical Dimension:MM

High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit 1

Technical Features



The motor input part is shown as four needles, but it can be used in various forms such as PCB, FPC, and connecting line according to customer requirements.
The size and shape of the mounting plate can be changed according to customer requirements.
At the same time, we can match the corresponding drive system to meet the needs of customers!

Our team has more than 10 years of stepper motor design, development and production experience, so we can achieve product development and auxiliary design according to the special needs of customers! Customer needs is our efforts, please feel free to contact!



About Micro stepper motor:



Our micro stepper motors generally have 18 degrees step angle.(Full step driving)
That means it takes 20 steps to rotate one turn.
Motor’s step angle is related to internal stator’s design.

We have micro stepper motors with different diameters, and motor’s torque is related to its size.
Here is relationship between motor’s diameter and torque(with suitable running frequency, at rated voltage):
6mm motor: about 1 g*cm
8mm motor: about 3g*cm
10mm motor: about 5 g*cm
15mm motor: about 15 g*cm
20mm motor: about 40 g*cm

Typical Applications

The 6mm micro stepper motor is a popular choice for a wide range of applications due to its small size, precision, and reliability. Here are some of the areas where this type of motor is commonly used:



Smart Security Products: The 6mm micro stepper motor is used in various smart security products such as access control systems, smart door locks, and surveillance cameras. These products require precise and reliable motors to ensure smooth and accurate movement.



Camera Lenses: The 6mm micro stepper motor is also used in camera lenses, including digital cameras, DSLRs, and action cameras. They are used to control the focus and zoom functions of the lenses.



Wearable Devices: The 6mm micro stepper motor is a popular choice for wearable devices such as smartwatches, fitness trackers, and other portable devices. These devices require small, lightweight, and energy-efficient motors.



Medical Devices: The 6mm micro stepper motor is used in various medical devices such as pumps, dispensers, and analyzers. These devices require precise and reliable motors to ensure accurate dosing and analysis.



Robotics: The 6mm micro stepper motor is used in various types of robots, including industrial robots, robotic arms, and humanoid robots. These robots require precise and reliable motors for smooth and accurate movement.



Consumer Electronics: The 6mm micro stepper motor is used in various consumer electronics products such as smartphones, tablets, and laptops. They are used for various functions such as haptic feedback, vibration, and camera control.



Automotive Applications: The 6mm micro stepper motor is used in various automotive applications such as electric power steering, throttle control, and HVAC controls. These applications require precise and reliable motors to ensure smooth and accurate operation.



Industrial Automation: The 6mm micro stepper motor is used in various industrial automation applications such as CNC machines, 3D printers, and textile machines. These applications require precise and reliable motors for precise and repeatable movement.



the 6mm micro stepper motor is a versatile motor that finds applications in a wide range of products and industries. Its small size, precision, and reliability make it an ideal choice for many applications.

Specifications

Product Name 6mm micro stepper motor
Model VSM0613
Rated Voltage 3.3V
Current Per Phase  200mA /phase
Coil Resistance 18Ω±7%
No. Of phase 2  Phases
Step Angle 18 degree
Excitation Method 2 Phase Excitation
Drive Mode Bipolar Drive
Pull-In Torque More Than 0.8gf.cm At 800 pps
Pull-Out Torque More Than 1.0gf.cm At 800 pps
Noise 45dB(Max.)
Max. Response Frequency More Than 1300 pps,No Load
Max. Starting Frequency More Than 2500 pps,No Load
Insulation Class Class E for Coils
Insulation Strength 100V AC for One Second
Insulation Resistance 1MΩ (Min)
Operating Temperature Range -10~+60℃
Weight 1.58g(Ref.)
OEM & ODM SERVICE AVAILABLE



Competitive Advantage



The 6mm micro stepper motor is a popular choice for many applications due to its numerous advantages over other types of motors. Here are some of the key advantages of the 6mm micro stepper motor:



Small Size: The 6mm micro stepper motor is one of the smallest motors available, making it ideal for applications where space is limited. Its small size also makes it lightweight and easy to integrate into small devices.



Low Power Consumption: The 6mm micro stepper motor is energy-efficient, consuming less power than other types of motors. This makes it an ideal choice for battery-powered devices, where energy efficiency is critical.



Precise Positioning: The 6mm micro stepper motor is capable of precise positioning, making it ideal for applications that require accurate and repeatable movement. Its ability to move in precise steps also makes it ideal for applications that require precise control over speed and torque.

Easy to Control: The 6mm micro stepper motor is easy to control, thanks to its simple design and precise stepping. It can be controlled using a simple driver circuit, without the need for complex feedback systems.



High Reliability: The 6mm micro stepper motor is highly reliable, with a long lifespan and low failure rate. It is also resistant to shock and vibration, making it ideal for use in harsh environments.



Low Noise: The 6mm micro stepper motor produces very little noise, making it ideal for applications where noise is a concern. This makes it an ideal choice for applications such as camera lenses and robotics.



Low Cost: The 6mm micro stepper motor is relatively inexpensive, making it an ideal choice for cost-sensitive applications. Its low cost also makes it an attractive option for mass-produced products.



the 6mm micro stepper motor offers numerous advantages over other types of motors. Its small size, low power consumption, precise positioning, ease of control, high reliability, low noise, and low cost make it an ideal choice for many applications.

Torque Curve For Reference

High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit 2

Product Detail Presentation

High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit 3

High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit 4

High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit 5



Type Of Wire Connect For Reference

Motor input method with Pin type, FPC, PCB, Lead wire etc.

These can be customized according to customer needs.

High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit 6



Type of Fixture Cover

The regular models are shown in the figure, and the special sizes can be customized.

High Speed 2 Phase 4 Wire Micro Stepper Motor 6mm Pm Stepper Motor Long Life Span $2~$5/Unit 7

Lead Time and Packaging Information:



Lead time for samples:
Standard motors in stock: within 3 days
Standard motors not in stock: within 15 days
Customized products: About 25~30 days (based on complexity of customization)

Lead time for building a new mold: generally about 45 days

Lead time for mass production: based on order quantity

Packaging:
Samples are packed in foam sponge with a paper box, shipped by express
Mass production, motors are packed in corrugated cartons with transparent film outside. (shipping by air)
If shipped by sea, product will be packed on pallets
