12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio

12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio

  • 12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio
  • 12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio
  • 12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio
  • 12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio
  • 12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio
12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio
Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: VIC-TECH
Certification: RoHS
Model Number: N20-GB12-298-M4
Payment & Shipping Terms:
Minimum Order Quantity: VIC-TECH
Price: $3.2~$6/unit
Packaging Details: Standard export package, or can be customized
Delivery Time: 15-30 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000000Units per year
Contact Now
Detailed Product Description
Model No.: N20-GB12-298-M4 Motor Diameter: 20mm
Rated Voltage: 12 V DC No. Of Phases: 2 Phases
No Load Current: 40 MA No Load Speed: 67 Rpm
Load Speed: 57rpm Load Current: 85mA
Stall Current: 0.35A Gear Ratio: 298:1
High Light:

20mm Brushed Small DC Stepper Motor

,

12V DC Stepper Motor

,

20000rpm Small DC Gear Motor

12V DC Diameter 20mm Brushed Small DC Stepper Motor With Reduction Ratio, The Reduction Ratio Can Be Selected​

This product is a DC gear motor, using precious metal brushed DC motor and precision metal gear box. The external dimension is oblate, the outer diameter is 12, the flat potential is 10, the length of the motor is 18mm, the length of the gear box is 9MM, the M4 screw, the DC motor is widely used due to its mature technology, low price and simple drive control. In cameras, copiers, electronic locks, lock cylinders, optical drives, precision instruments, cameras and other fields.
After matching the gearbox, the torque is greatly increased, the speed is reduced, and it is easy to control!
The gearbox is processed and assembled by imported machine tools to ensure that the precision of each gear is higher than other manufacturers in the same industry, so the gearbox has stable transmission, low noise, high efficiency, reliable structure, long life and stable quality.
Selectable gear ratios: 2:1 5:1 10:1 20:1 30:1 36:1 50:1 63:1 67:1 89:1 100:1 110:1 120:1 150:1 172: 1 210:1 250:1 275:1 298:1 380:1 420:1 500:1 600:1 1000:1

Our team has more than 10 years of experience in the design, development and production of micro motors, and can realize product development and auxiliary design according to the special needs of customers!
If you are interested, you can write to me.



Mechanical Dimension:MM

12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio 0

Typical Applications

  • Office Automatic Equipments
  • Printer/paper Feeder
  • Bank Equipments
  • Safe Box
  • Ad Equipment
  • Household Appliances
  • Electtric Door Locks



parameter



Motor diameter

20mm

Rated voltage

12V dc

No Load Current

40mA

No load speed

67rpm

Rated speed

20000rpm

load current

85mA

Rated torque

0.34kgf.cm

Stall torque

2.2kgf.cm

Stall current

0.35A

Gear ratio

298:1






Motor characteristic curve:





12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio 1



Product Detail Presentation

12V DC Diameter 20mm Brushed micro dc gear motor With Reduction Ratio 2
